Fuse holder base 2P 1000 V DC 10×38 with indicator Mersen
Manufacturer: Mersen
INDEX: CUS102I
The fuse holder bases of the Modulostar CUS10 series by Mersen are safe to use, even during fuse replacement, and are built to IEC standards to provide IP20 protection.
Modulostar CUS10 fuse holders are available in single-, double-, triple- or four-pole versions, with or without a visual blown fuse indicator. They are made of durable thermoplastic or thermoset material, depending on the version. They are designed for use with Mersen midget fuses.
Product features:
- 2-pole
- Compact, space-saving design
- Degree of protection IP20
- DIN rail mounting
- Easy access to the fuse
- Lockable without accessories
- Sealable in closed & open position
- Visual blown fuse indicator
- UL94V2 mini plastic material
- R22HL2 plastic material for railway applications
- Flame retardant materials with glow wire flammability index to 960 °C
- Shock and vibration tested for marine and railway applications
| Width - number of modules: | 2 |
|---|---|
| Dimensions [mm]: | 35 x 79.3 x 61.1 |
| DC protection type: | Fuse base |
|---|---|
| Max. voltage [V]: | 1000 |
| Max. current [A]: | 32 |
